Product details of the eps cutting machine
Quick Detail
Our material for eps cutting machine is different from other companies' material and it's better. Our quality management system ensures that our products meet international quality standards. Minglong has found its growing popularity and acceptance among overseas customers.
Product Information
eps cutting machine's details are presented to you in the following section.
Characteristics
1. This machine use for producing the shape forming packing products and some construction products, and it applies computer to control the whole process automatically, low voltage and high efficiency, fast forming, saving energy and big capacity.
2. It use advanced vacuum, condenser, and hydraulic system, different kind of heating, feeding and cooling. It can install the small and big mold.
3.There are four kinds of operating mode (Automatic, Semi-automatic, Middle-startup and Manual operation)with safe-guard protective device to ensure safe operation. Perfect failure self-diagnosing and overloading protection system, which keep machine safe and steady working.
4..Most of the main components are of world-famous brands, with reliable performance, stable quality, long service life and low maintenance cost.
5. This machine can choose mechanical ejection mold mode or hydraulic ejection mold mode.
6. This machine has the fast installing mold system.
Technical Data
ITEM | Unit | FAV1400 | FAV1750 | FAV2000 | |
Mould Dimension | mm | 1400*1250 | 1750*1450 | 2000*1650 | |
Max product | mm | 1250*1100*420 | 1600*1300*420 | 1850*1500*420 | |
Stroke | mm | 150~1500 | 150~1500 | 150~1500 | |
Steam | Entry | mm | 89/108 | 108 | 125 |
Consumption | kg/cycle | 6~9 | 6~11 | 8~13 | |
Pressure | Mpa | 0.5~0.7 | 0.5~0.7 | 0.5~0.7 | |
Cooling water | Entry | mm | 89/108 | 108 | 125 |
Consumption | kg/cycle | 30~90 | 35~100 | 40~130 | |
Pressure | Mpa | 0.4~0.6 | 0.4~0.6 | 0.4~0.6 | |
Compressed Air | Entry | mm | 50/76 | 76 | 76/89 |
Consumption | m3/cycle | 1.8 | 2 | 2.5 | |
Pressure | Mpa | 0.5~0.7 | 0.5~0.7 | 0.5~0.7 | |
Vaccum Pump Capacity | m3/h | 230 | 290 | 290 | |
Cycle Time | s | 60-120 | 60-120 | 70-140 | |
Connected Load/Power | kw | 12.5 | 16.5 | 16.5 | |
Overall Dimension | mm | 5700*1920*3250 | 5700*2030*3450 | 5700*2240*3680 | |
Machine Weight | kg | 6500 | 7500 | 9500 |
Advantages
1. Fully automatic working by computer control system with PLC and color touch screen.
2.Fast working process and short cycle time, Saving energy and high efficiency working capacity.
3. Germany and Japan proportional valves, meters, sensors, reduce valve, Europe pipe system and Schneider electronics to control steady steam and air pressure for steady working and making high quality products.
4. The machine has fast installing mold and auto locking mold system, and with foundation legs and electric crane, feeding oil system, single vacuum and condenser system.
5. The machine made by more thickness steel plates, bigger pipes &valves and stronger machine structure for high efficient working capacity and long working life.
6. Excellent machine design with easy installation,operation and maintenance, good welding and painting, beautiful appearance of the complete machine.
Function And Application
It used for running EPS molds to produce all kinds of packaging and insulation products such as seafood/fruit/vegetable/ice boxes, packing products, tools, decoration, cold storage, ICF constructions, cars and Appliances inner parts and so on.
Company Introduction
Hangzhou Minglong Technology Co.,Ltd (Minglong), is a company integrating production, processing, and sales. The main products are EPS machine, EPP machine. Looking forward to the future, Minglong will continue to follow the development philosophy of 'people-oriented, technology-leading'. We will gather talents based on the business strength and motivate them by a reasonable system. Relying on the power of sci-tech, we will strive to build an excellent brand in the industry and spread the sales network to the country and to the even wider international market. We have the powerful team management, strong production team, customer-focused business team, and inexorable research and development team to offer favorable conditions for our development. Minglong is able to meet customers' needs to the greatest extent by providing customers with one-stop and high-quality solutions.
Our products are of excellent quality and favorable price, winning a wide recognition. If you want to know more about the products, please contact us!
