Minglong Eps Block Moulding Machine Eps Block Moulding Machinesupplier
Product details of the eps block moulding machine
Product Overview
Being expertly conceived, Minglong eps block moulding machine shows an award-winning design. The product is not only powerful but also durable, and has a longer life than other competing products. With advanced manufacturing equipment and perfect quality guarantee system, Hangzhou Minglong Technology Co.,Ltd supplies the clients with high quality products.
Product Introduction
Compared with other products in the same category, Minglong's eps block moulding machine has the following advantages.
Characteristics
1.This pre-expander has a big capacity, apply the imported spare parts such as the Germany and Japan famous brand, the products with very small tolerance.
2. The machine has the drying system inside barrel, and with the drying bed for second drying.
3. The machine design with advanced design and making, It use several steam pipes into the barrel which keep the steam equality for the same size EPS beads and high quality products. The machine bottom has several clean door which can clean the barrel inside anytime, it is easy to repair and operation. The feeding and weighing system can be put on the top of the machine, which can save the space of the workshop.
4. The machine use the high quality material to make, the barrel and main spindle and mix rods, material hopper and door all use the 304 Stainless steel, the main barrel has three layers, very few problems, with a long working time.
5. The machine with the function of auto adjusting the density of the material.
Technical Data
| ITEM | FDS930A/B | FDS1100A/B | FDS1400I-II | FDS1670I-II | |
| Expansion Chamber | Diameter | DN930 | DN1100 | DN1400 | DN1660 |
| Volume | 0.9m3 | 1.4m3 | 2.1m3 | 4.8m3 | |
| Steam | Consumption | 4-6kg/cycle | 6-8kg/cycle | 8-10kg/cycle | 11-14kg/cycle |
| Compressed Air | Consumption | 0.5-0.7m3/cycle | 0.9-1.1m3/cycle | 0.5-0.8m3/cycle | 0.7-1.1m3/cycle |
| Pressure | 0.5-0.8Mpa (5-8bars) | ||||
| Capacity | 4g/l | 250kg/h | 360kg/h | ||
| 9g/l | 230kg/h | 320kg/h | 450kg/h | 560kg/h | |
| 15g/l | 320kg/h | 550kg/h | 750kg/h | 900 kg/h | |
| 30g/l | 670kg/h | 850kg/h | 1000kg/h | 1350 kg/h | |
| Connected Load/Power | 15.5KW | 17.5KW | 22.5KW | 24.5KW | |
| Expanded Density | 10-100kg/m3 | 10-40kg/m3 | 4-40kg/m3 | 4-40kg/m3 | |
| Density Tolerance | <±2.5% | <±3% | <±3% | <±3% | |
| Overall Dimension(cm) | 290×420×590 | 290×450×590 | 650×450×450 | 900×350×550 | |
| Machine weight | 2700kg | 3200kg | 4500kg | 4800kg | |
Advantages
1. Fully automatic working by computer control system with PLC and color touch screen.
2. Have two expansion stages for making both low and high density products.
3. Use Germany and Japan proportional valves, sensors, reduce valve to control steady steam & air pressure, uniform steam coming to keep steady working and making high quality products.
4. Have the weight and density adjusting control system to get high accurate density products.
5.Have auto drying system, feeding system, weigh system, high efficient working and big capacity.
6. The machine made by 304 Stainless steel and all solid mix screws for long working life.
7. The machine excellent design and strong body structure, easy installation,operation and maintenance, good welding and painting, beautiful appearance of the complete machine.
Detail Of Key Parts
Production Process
Function And Application
It used for making the EPS raw material expansion into EPS foam beads, which used for producing all kinds of packaging and insulation products such as seafood/fruit/vegetable/ice boxes, packing products, tools, decoration, cold storage, constructions and so on.
Company Advantages
Located in Hangzhou Minglong Technology Co.,Ltd (Minglong) is a company that mainly provides EPS machine, EPP machine. With the concept of benefiting the people and gaining win-win with the public, we focus on creating excellent services that guide us to move forward all the way with the initial heart. We are willing to go hand in hand with you to create a better future.
