Company Advantages
· Hangzhou Minglong Technology Co.,Ltd put great importance into outline of eps machine.
· Compared with other products, this product has obvious advantages, longer service life and more stable performance. It has been tested by authoritative third parties.
· The advance technology of Minglong allows customers to enjoy the high performance of eps machine.
Introduction
It used for cooling the hot water for machine working such as the EPS/EPP(Polystyrene/Styrofoam) machine working. We manufacture different size cooling tower for our machine, we can specially design and make if the customer need different request.
The cooling tower with water pump effectively reduces the high temperature of water by using a powerful water pump to circulate the hot water through the tower's fill media, allowing for efficient evaporation and cooling. This reliable and durable system provides essential water cooling for industrial applications, ensuring optimal performance and longevity of equipment. Its compact and space-saving design, along with low power consumption, makes it an environmentally friendly and cost-effective solution for managing high water temperatures.
◎ Powerful water pump
◎ Well-designed tower structure
◎ Durable, easy maintenance, and compact design
CT-50 Cooling tower specification
Item | specification | data | note |
Base Data | TYPE | Counterflow round towers | |
MODEL | CT-50 | LOW NOISE | |
SIRCLE VOLUME | 50m3/h | ||
IN WATER/OUT WATER TEMPERATURE | 37℃/32℃ | ||
DRY/HUMITITY | 31.5℃/27℃ | ||
COOLING CAPACITY | 195,200 kcal/h | ||
NOISE | 57.5dB(A) | 16m DISTANCE | |
POWER | 380V/3P/50Hz | ||
WATER PH | PH=6-8 | ||
Design data | AIR : WATER | 0.62kg/kg | |
WATER LOST | ≤0.02% | ||
STEAM LOST | ≤0.833% | ||
NET WEIGHT | 190kg | ||
RUNNING WEIGHT | 975kg | ||
Fan Data | FAN | Axial flow | |
FAN VOLUME | 21,580m3/h | ||
FAN SPEED | 910r/min | ||
FAN DIA(F) | 890 mm | ||
Leaf number | 4PCS/SET | ||
WORKING FORM | DIRECT DRIVE | ||
MOTOR SPEED | 910r/min | ||
MOTOR POWER | 1.5 kW | ||
MOTOR START | DIRECT START | ||
Main size | TOWER DIA(F) | 1,810mm | |
TOWER HEIGHT(H) | 2,305mm | ||
IN PIPE/OUT PIPE(DN) | 80mm/80mm | ||
FULL PIPE/DRAIN(DN) | 25mm/25mm | ||
AUTO SUPPLY(DN) | 15mm | ||
material | MOTOR | Totally enclosed type waterproof | |
FAN | A.B.S | ||
BODY | GLASS STEEL F.R.P | High quality glass fiber mat And resin synthesis | |
WATERBATH | |||
SPAY WATER SYSTEM | P.V.C | ||
INFILL FILM | P.V.C/PP | Flame retardant type | |
Floating ball valve | P.V.C | ||
FEEDING AIR SYSTEM | P.V.C |
Function And Application
It used for cooling the hot water for working machine such as the EPS/EPP(Polystyrene/Styrofoam) machine working. We manufacture different size cooling tower for our machine, we can specially design and make if the customer need different request.
Company Features
· Hangzhou Minglong Technology Co.,Ltd is a long-established company based in China. Over the years, we are engaged in the research, development, and production of eps machine.
· We have a team of R&D talents who always pursue industry specialization. They have been concentrating on forming our own core competence and advantage of product innovation, which has obtained us great success.
· Under the principle of win-win cooperation, we always working hard to seek for long term partnership with all our customers. We will allow our customers to engage with the business and strengthen interaction with them about the product and services. Through this way, we can incentivize them to keep coming back.
Product Details
Our company starts from the whole and excels in detail in the production of eps machine. So our products have better performance in the following aspects.
Enterprise Advantages
Minglong's experienced and professional technical personnel ensures excellent product design and development.
Our company owns a comprehensive after-sales service system and information feedback channels. Thus, we can provide customers with a full range of service guarantees and effectively solve customers' problems.
Our company always adheres to the business philosophy of 'customer first, technological innovation'. In order to obtain better economic and social benefits, we constantly learn advanced management methods and scientific production techniques to promote the rapid upgrading of the industry.
Since the establishment in Minglong has experienced wind and rain all the way for years, and has continued to grow and develop. Now, we finally occupy a certain place in industry.
Under the constant market development and product innovation, our company has gradually established a market strategy. In this way, we focus on the sales of key products and the expansion of the domestic market, and then realize the product layout in the national region.
