Lost foam Pre-expander for EPS Bead Manufacturing
EPS Styrofoam Making Beads Machine Pre-expander
Lost foam Pre-expander for EPS Bead Manufacturing is designed for EPS Styrofoam factory who is focused on producing high-density foam beads special for lost foam coating application, the EPS density from 15kg/m3 up to 50kg/m3, it’s a small but accuracy pre-expander machine with less steam consumption.
5.0
like
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Characteristics
Lost foam Pre-expander for EPS Bead Manufacturing
- Accuracy, less steam consumption
- Adopts PLC and Touch screen control system
- Electronic parts and valves are famous brands
- Fully automatic lost foam pre-expander with stable quality
Technical Data
| ITEM | FDS930A/B | FDS1100A/B | FDS1400I-II | FDS1670I-II | |
| Expansion Chamber | Diameter | DN930 | DN1100 | DN1400 | DN1660 |
| Volume | 0.9m3 | 1.4m3 | 2.1m3 | 4.8m3 | |
| Steam | Consumption | 4-6kg/cycle | 6-8kg/cycle | 8-10kg/cycle | 11-14kg/cycle |
| Compressed Air | Consumption | 0.5-0.7m3/cycle | 0.9-1.1m3/cycle | 0.5-0.8m3/cycle | 0.7-1.1m3/cycle |
| Pressure | 0.5-0.8Mpa (5-8bars) | ||||
| Capacity | 4g/l | 250kg/h | 360kg/h | ||
| 9g/l | 230kg/h | 320kg/h | 450kg/h | 560kg/h | |
| 15g/l | 320kg/h | 550kg/h | 750kg/h | 900 kg/h | |
| 30g/l | 670kg/h | 850kg/h | 1000kg/h | 1350 kg/h | |
| Connected Load/Power | 15.5KW | 17.5KW | 22.5KW | 24.5KW | |
| Expanded Density | 10-100kg/m3 | 10-40kg/m3 | 4-40kg/m3 | 4-40kg/m3 | |
| Density Tolerance | <±2.5% | <±3% | <±3% | <±3% | |
| Overall Dimension(cm) | 290×420×590 | 290×450×590 | 650×450×450 | 900×350×550 | |
| Machine weight | 2700kg | 3200kg | 4500kg | 4800kg | |
Detail Of Key Parts
Color screen monitor
German and Japan valves
German and Japan valves
Production Process
Function And Application
Lost foam Pre-expander for EPS Bead Manufacturing used for making the EPS raw material expansion into EPS foam beads, which used for producing all kinds of packaging and insulation products such as seafood/fruit/vegetable/ice boxes, packing products, tools, decoration, cold storage, constructions and so on.
